Oil Spray Machine PY600
This oil sprayer is equipped with 6 high-precision spray guns, which support synchronous multi-point spraying, greatly improving the efficiency of oil spraying, and is particularly suitable for large-scale food processing scenarios. Combining the constant pressure oil supply system and advanced spray technology, the machine can achieve a fine, uniform and stable spraying effect, ensuring uniform coverage of the food surface and improving product quality and consistency.
The equipment structure design is flexible and can be widely used in conjunction with a variety of production facilities such as baking trays, molds, and conveyor lines, and can easily adapt to different process flows. The operation interface is simple and intuitive, supporting quick parameter setting and one-button start, significantly improving the convenience of operation and production efficiency.
Various sized baking trays, bread pans, muffin pans, cake pans and moulds.
1500×910×1100mm
- It applies to spraying oil to the bottom and sides of the toast box, flat-bake plates, cake molds, etc.
- It is equipped with high precision spray nozzles and stable constant voltage system, precise fluid, gas flow mixing ratio control functions, contributing to high quality micro-particle spray effects and precision spraying, not generating splashing and fog.
- The pressure control system has high safety performance, with an automatic pressure relief protection device when the pressure is too high.
- It adopts a compact modular design and residual fluid collecting device, making the operating environment more clean and facilitating the cleaning.
√ Stand-alone machine or online machine.
√ Numbers of spray gun.
| Model | PY600 | PY602 | Configurable Options: Standard configuration: 6 spray gun system, 2 Storage tanks (18L), excluding conveyor line (to be used with conveyor line) |
| Power | 1.0KW | 1.0KW | |
| Voltage/Frequency | 220V/50HZ | 220V/50HZ | |
| Compressed Air Pressure & Fow | 0.4-0.6MPa 350L/min | – | |
| Capacity | 5~12trays/min | 5~12trays/min | |
| Hopper Volume | – | – | |
| Dimension (L*W*H) mm | 1500*910*1100 | 1700*1430*1465 |
